MB(L) Lock Washers

1/4	MB(L) Lock Washers Previous N and AN inch Lock Nuts Next KMK Lock Nut With Innner Locking Pin +86-15051683850

Product Description
Product Model

Description

MB(L) Lock Washers

Principal dimensions			Designation
d	d₂	B
mm
10	21	1	MB 0
12	25	1	MB 1
12	25	1.2	MB 1 A
15	28	1.2	MB 2 A
15	28	1	MB 2
17	32	1.2	MB 3 A
17	32	1	MB 3
20	36	1.2	MB 4 A
20	36	1	MB 4
25	42	1.8	MB 5 A
25	42	1.25	MB 5
30	49	1.8	MB 6 A
30	49	1.25	MB 6
35	57	1.8	MB 7 A
35	57	1.25	MB 7
40	62	1.8	MB 8 A
40	62	1.25	MB 8
45	69	1.8	MB 9 A
45	69	1.25	MB 9
50	74	1.8	MB 10 A
50	74	1.25	MB 10
55	81	1.5	MB 11
55	81	2.5	MB 11 A
60	86	1.5	MB 12
60	86	2.5	MB 12 A
65	92	1.5	MB 13
65	92	2.5	MB 13 A
70	98	1.5	MB 14
70	98	2.5	MB 14 A
75	104	1.5	MB 15
75	104	2.5	MB 15 A
80	112	1.75	MB 16
80	112	2.5	MB 16 A
85	119	1.75	MB 17
85	119	2.5	MB 17 A
90	126	1.75	MB 18
90	126	2.5	MB 18 A
95	133	2.5	MB 19 A
95	133	1.75	MB 19
100	142	1.75	MB 20
100	142	2.5	MB 20 A
105	145	1.75	MB 21
110	154	1.75	MB 22
115	159	2	MB 23
120	164	2	MB 24
120	152	2	MBL 24
125	170	2	MB 25
130	175	2	MB 26
130	161	2	MBL 26
135	185	2	MB 27

DSQ has well-knows as one of the credible suppliers of mb(l) lock washers. With many warehouse and qualified distributors spread around the world, our company can not only assure you the quality of this mb(l) lock washers but also great after-sale service and timely delivery of our products. Waiting for your contact with our agent!
