30300 SERIES

Roller Bearings > Tapered Roller Bearings > Metric Size Single Row Tapered Roller Bearings > 30300 Series

30300 Series.pdf

Structure classification:

Single row tapered roller bearings

Double row tapered roller bearings

Four-row tapered roller bearings

Size Range:

Single row tapered roller bearings

Inside diameter size range: 20 mm - 1270 mm

Outside diameter size range: 40 mm - 1465 mm

The width of the size range: 15 mm - 240 mm

Double row tapered roller bearings

Inside diameter size range: 38 mm - 1560 mm

Outside diameter size range: 70 mm - 1800 mm

The width of the size range: 50 mm - 460 mm

Four-row tapered roller bearings

Inside diameter size range: 130 mm - 1600 mm

Outside diameter size range: 200 mm - 2000 mm

The width of the size range: 150 mm - 1150 mm

Series Range

30000, A、B、X、CD、TD
